Wooden Wireless Charger

Input voltage: dc4.3v ~ 5.5v/1.5 ~ 2A.

If the voltage exceeds this range, alarm and stop charging

Output voltage: 5V ± 0.1V,

Charging current: 1A

Charging power: up to 5W

Conversion efficiency: more than 73%

Transmission distance: the maximum is 10mm, and the recommended transceiver spacing is 2mm ~ 4mm

Standby power consumption: the average power consumption is less than 50MW

Over temperature protection: when the temperature is higher than 60 ° during charging, it will automatically stop charging for 1 minute, and then recharge after the temperature drops

Overcurrent protection: when the output current is greater than 1.5A during charging, the charging will be stopped automatically to prevent damage to the charger

Executive standard: Qi wireless charging standard

Product specification: 92 * 92 * 8mm
